| Place of Origin: | China |
| Brand Name: | AMEISON |
| Certification: | ISO 9001: 2008 |
| Model Number: | AMXP-2400-18 |
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | EXW Price |
| Packaging Details: | PP bag /inner box/master carton or customized |
| Delivery Time: | 10-20 working days |
| Payment Terms: | TT,Paypal,Western Union |
| Supply Ability: | 50,000 Pieces per Month |
| Frequency Rang: | 2400-2500MHz | Gain: | 18dBi |
|---|---|---|---|
| Polarization: | Vertical | Type: | Extenal |
| Connector: | N Female | ||
| Highlight: | directional antenna,wifi antenna directional,directional antenna wifi |
||
2.4GHz wifi antenna:
2400-2500MHz
18dBi
Manufacturer produce
2.4 GHz WIFI WLAN System ISM, etc.
Feature:
High Gain
H or V Polarization
Full day for working
Durable, corrosion resistance
Optimized dimension
Application:
2.4 GHz WIFI WLAN System ISM, etc
Sector signal coverage
Base station &Repeater station system
Wireless telecommunication & Data transmission system
|
AMXP-2400-18 Electric Specifications |
|
|
Frequency rang |
2400-2500 |
|
Polarization |
Vertical |
|
Gain(DBi) |
18 |
|
Beamwidth(0°) |
H:65 V:38 |
|
F/B ratio(DB) |
≥25 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.5 |
|
Max power(W) |
100 |
|
Mechanical Specifications |
|
|
Connector model |
N Female |
|
antenna size (mm) |
650*175*80 |
|
Packing size(mm) |
680*200*150 |
|
Antenna weight (kg) |
3.8 |
|
Radome material |
UPVC |
|
Radome color |
Gray |
|
Mechanical tilt(°) |
0~10 |
|
Working Temperature(°c) |
-40~60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Pole diameter(mm) |
50~75 |
